| RITE-ON
Harnesses |
| The
North RITE-ON harnesses are extremely easy to don and incredibly comfortable to wear. Integral back and shoulder padding provides
all-day comfort. It also
allows the harness to keep its shape, so that the straps remain tangle-free
and donning is no more difficult than putting on a jacket. Available in one, three and four D-ring
versions, RITE-ON harnesses also feature fast-action bayonet style connectors
on chest and leg straps, and an optional dorsal D-ring extender.
|
|
Universal
Size |
| |
|
Fall
Arrest Harnesses |
| |
|
Part
# |
Description
|
Applications
|
Weight
(lbs.)
|
 Click
above for a larger picture. |
FP81F/1DBA
|
RITE-ON
universally sized harness - 1 back (dorsal) D-ring.
|
Fall arrest.
|
3.4
lbs.
|
FP81F/1EDBA
|
RITE-ON
universally sized harness - 1 back (dorsal) D-ring with 18” extender.
|
Fall
arrest.
|
3.7
lbs.
|
FP81F/3DDA
|
RITE-ON
universally sized harness - 1 back (dorsal) D-ring, 2 side positioning
D-rings.
|
Fall
arrest, work positioning.
|
4.2
lbs.
|
FP81F/3EDDA
|
RITE-ON
universally sized harness - 1 back (dorsal) D-ring with 18” extender
and 2 side positioning D-rings.
|
Fall
arrest, work positioning.
|
4.5
lbs
|
FP81F/4DLA
|
RITE-ON
universally sized harness - 1 back (dorsal) D-ring, 2 side D-rings and
1 sternal D-ring.
|
Fall
arrest, work positioning. Ladder climbing.
|
4.6
lbs.
|
| |
|
FP81F/4EDLA
|
RITE-ON
universally sized harness - 1 back (dorsal) D-ring with 18” extender,
2 side
D-rings and 1 sternal D-ring.
|
Fall
arrest, work positioning. Ladder climbing.
|
4.9
lbs.
|
FEATURES
|
BENEFITS
|
Integral
back and shoulder pad
|
·
Pad conforms to the
user’s shape to provide all-day comfort. Even in hot conditions,
the pad is breathable and wicks sweat, so that the user remains comfortable.
·
The pad prevents the
harness straps from tangling, making donning as easy as putting on a
jacket. Tangled straps are a non-compliance and compromise user safety.
|
Fast-Action
Bayonet Style Connectors
|
·
Can be connected with
a single action, in a fraction of the time taken with conventional buckles.
This means that users are more likely to use them, and maintain their
safety.
|
Double
Action Release
|
·
The bayonet connectors
require two actions to release, thus avoiding accidental opening.
|
Extended
D-ring Option
|
·
Makes lanyard attachment
easier and allows the user to check for 100% snap hook gate closure.
|
D-ring
Options
|
·
D-rings are available
on the chest strap for ladder climbing and on the sides for positioning.
|
Polyester
Webbing
|
·
Is light in weight,
and offers superior chemical resistance.
|
Standards
|
·
RITE-ON harnesses
meet or exceed ANSI and OSHA requirements and are CSA approved.
|
RITE-ON
Harness Specifications |
| Size: |
Universal fit |
| Color: |
Shoulder straps-black -- Leg straps-yellow |
| Usage: |
Dorsal D-ring attachment for fall arrest |
| Material - Webbing: |
Polyester
1-3/4 inches (45 mm.) wide |
| |
Minimum tensile strength 5,000 lbs.
(22.2 kN) |
| Back Pad: |
1/4 inch Pro-Mesh Embodied Pad |
| Hardware: |
9225
Quick Connect Buckle- material 4130 -minimum tensile strength 4,000lbs. |
| |
Forged D-ring: Sheet – alloy
steel -Minimum breaking strength 5,000 lbs (22 kN) |
| |
D-ring 100% proof loaded to 3,600 lbs
(16 kN) |
| |
All hardware meets or exceeds ANSI
Z-359.1 and CSA Z259.12-00 requirements |
| Weight: |
See above |
| Attachment D-Ring Opening: |
D-ring opening 2-7/16 in. (62 mm.) |
| Thickness: |
0.290 in. (7.41 mm.) |
| Capacity: |
One
worker of max 310 lbs (140 kg) combined weight of person, tools, clothing,
etc. |
| Maximum Arresting Load: |
8
kN (1,800 lbs.)
|
| Operating Temperature: |
-35°C to +35°C (-31°F to 95°F)
|
STANDARDS |
| Certified: |
CAN/CSA Z259.10 –M90 Full Body Harness Class
A |
| Compliance: |
ANSI
Z359.1 and A10.14-1991 Class III OSHA 1910.66 App. C |
| Component Compatibility: |
North full body harnesses are designed
for use with North approved components or subsystems (lifelines, energy
absorbers, lanyards, rope grabs and self-retracting lifelines) or as recommended
by a qualified person |
| Warnings: |
See
Operating and Maintenance Instruction Manual for details. |
| Storage: |
Store
in a cool dry place away from chemicals, water, and corrosive environment. |
|
|
|
|
